BazisLib::Win32::NetworkFilterBase Class Reference

Allows filtering network connections on WINSOCK level. More...

#include <netfilter.h>

Inherited by BazisLib::Network::Filters::_DummyNetworkFilter, and BazisLib::Network::Filters::BasicHTTPFilter.

Collaboration diagram for BazisLib::Win32::NetworkFilterBase:

[legend]

List of all members.

Classes
struct	SystemSocketContext
struct	WinsockPointers
Public Member Functions
	NetworkFilterBase ()
ActionStatus	InstallFilter (BazisLib::Network::Filters::FilterMode mode, IDLLPatcher *pPatcher)
ActionStatus	UninstallFilter (IDLLPatcher *pPatcher)
	~NetworkFilterBase ()
Protected Member Functions
void	SignalDataReceivedEvent (void *pSystemContext)
	Fires the 'receive ready' event.
virtual BazisLib::ActionStatus	OnStartConnect (BazisLib::Network::_PlatformSpecificInternetAddress *pAddr, void **ppUserContext)
virtual void	OnDisconnect (void *pSystemContext, void *pUserContext)
virtual size_t	OnSend (void *pSystemContext, void *pSystemContext2, void *pBuf, size_t MaxSize, void *pUserContext, bool ForceBlockingMode)
virtual size_t	OnReceive (void *pSystemContext, void *pSystemContext2, void *pBuf, size_t MaxSize, void *pUserContext, bool ForceBlockingMode)
virtual void	FreeUserContext (void *p)
Private Types
enum	{ FilteredEventReceive = 0, FilteredEventCount }
enum	{ SystemSockReceivedData = 0x0002 }
typedef int	len
typedef int int	flags
typedef int	len
typedef int int	flags
typedef struct sockaddr *	name
typedef struct sockaddr int	namelen
typedef std::map< SOCKET, SystemSocketContext * >	ContextMap
typedef int(WSAAPI *	WSAConnect_ptr )(IN SOCKET s, IN const struct sockaddr FAR *name, IN int namelen, IN LPWSABUF lpCallerData, OUT LPWSABUF lpCalleeData, IN LPQOS lpSQOS, IN LPQOS lpGQOS)
typedef SOCKET(WSAAPI *	socket_ptr )(IN int af, IN int type, IN int protocol)
typedef int(WSAAPI *	WSAEventSelect_ptr )(IN SOCKET s, IN WSAEVENT hEventObject, IN long lNetworkEvents)
typedef int(WSAAPI *	WSAEnumNetworkEvents_ptr )(IN SOCKET s, IN WSAEVENT hEventObject, OUT LPWSANETWORKEVENTS lpNetworkEvents)
Private Member Functions
typedef	int (WSAAPI *recv_ptr)(SOCKET s
typedef	__out_bcount (len) char *buf
typedef	int (WSAAPI *send_ptr)(SOCKET s
typedef	__in_bcount (len) const char *buf
typedef	int (WSAAPI *connect_ptr)(SOCKET s
typedef	int (WSAAPI *closesocket_ptr)(SOCKET s)
SystemSocketContext *	GetSystemContextForSocket (SOCKET s)
void *	GetUserContextForSocket (SOCKET s)
void	FreeAndRemoveContextForSocket (SOCKET s)
Static Private Member Functions
static int WSAAPI	recv_override (SOCKET s, __out_bcount(len) char *buf, int len, int flags)
static int WSAAPI	send_override (SOCKET s, __in_bcount(len) const char *buf, int len, int flags)
static int WSAAPI	connect_override (SOCKET s, const struct sockaddr *name, int namelen)
static int WSAAPI	WSAConnect_override (IN SOCKET s, IN const struct sockaddr FAR *name, IN int namelen, IN LPWSABUF lpCallerData, OUT LPWSABUF lpCalleeData, IN LPQOS lpSQOS, IN LPQOS lpGQOS)
static int WSAAPI	closesocket_override (SOCKET s)
static SOCKET WSAAPI	socket_override (IN int af, IN int type, IN int protocol)
static int WSAAPI	WSAEventSelect_override (IN SOCKET s, IN WSAEVENT hEventObject, IN long lNetworkEvents)
static int WSAAPI	WSAEnumNetworkEvents_override (IN SOCKET s, IN WSAEVENT hEventObject, OUT LPWSANETWORKEVENTS lpNetworkEvents)
Private Attributes
ContextMap	m_UserContextMap
InProcessMutex	m_ContextMapMutex
WinsockPointers	m_OriginalPointers
Static Private Attributes
static NetworkFilterBase *	m_pInstalledFilter

---

Detailed Description

Allows filtering network connections on WINSOCK level.

This class is a basic network filter for WIN32 environment. It acts by replacing import table pointers to WINSOCK functions by its own function pointers, using IDLLPatcher interface for that. The IDLLPatcher should be provided by caller.

Remarks:

As WINSOCK2 provides lots of functinality to work in different asynchronous and event-driven modes, not all of it is supported by this filter class. Basically, if the application uses some synchronization-related functions other than included in WinsockPointers structure, the filter may not work correctly. Present version supports the following strategies:

• Classic blocking mode without synchronization (WINSOCK v1)
• Sending/receiving with synchronization using WSAEventSelect()
• Using WSAEnumNetworkEvents() to get socket event state

The following strategies/cases are NOT supported:

• When the application first calls recv() that blocks, then send(), that sends some data, OnRecv() will be called before OnSend(), that may prevent the event sequence from being processed correctly (if OnRecv() in child class relies on some flags set by OnSend()).
• When the application uses WSARecv()/WSASend()/WSARecvEx()/WSASendEx()/ReadFile()/WriteFile() with sockets.

Attention:

As the current version does not support ALL winsock strategies, consider it to be EXPERIMENTAL and NOT compatible with ALL winsock-based apps.

---

Member Typedef Documentation

typedef std::map<SOCKET, SystemSocketContext *> BazisLib::Win32::NetworkFilterBase::ContextMap [private]

typedef int int BazisLib::Win32::NetworkFilterBase::flags [private]

typedef int int BazisLib::Win32::NetworkFilterBase::flags [private]

typedef int BazisLib::Win32::NetworkFilterBase::len [private]

typedef int BazisLib::Win32::NetworkFilterBase::len [private]

typedef struct sockaddr* BazisLib::Win32::NetworkFilterBase::name [read, private]

typedef struct sockaddr int BazisLib::Win32::NetworkFilterBase::namelen [read, private]

typedef SOCKET(WSAAPI * BazisLib::Win32::NetworkFilterBase::socket_ptr)(IN int af, IN int type, IN int protocol) [private]

typedef int(WSAAPI * BazisLib::Win32::NetworkFilterBase::WSAConnect_ptr)(IN SOCKET s, IN const struct sockaddr FAR *name, IN int namelen, IN LPWSABUF lpCallerData, OUT LPWSABUF lpCalleeData, IN LPQOS lpSQOS, IN LPQOS lpGQOS) [private]

typedef int(WSAAPI * BazisLib::Win32::NetworkFilterBase::WSAEnumNetworkEvents_ptr)(IN SOCKET s, IN WSAEVENT hEventObject, OUT LPWSANETWORKEVENTS lpNetworkEvents) [private]

typedef int(WSAAPI * BazisLib::Win32::NetworkFilterBase::WSAEventSelect_ptr)(IN SOCKET s, IN WSAEVENT hEventObject, IN long lNetworkEvents) [private]

---

Member Enumeration Documentation

anonymous enum [private]

Enumerator:

FilteredEventReceive
FilteredEventCount

anonymous enum [private]

Enumerator:

SystemSockReceivedData

---

Constructor & Destructor Documentation

BazisLib::Win32::NetworkFilterBase::NetworkFilterBase

(

)

BazisLib::Win32::NetworkFilterBase::~NetworkFilterBase

(

)

---

Member Function Documentation

typedef BazisLib::Win32::NetworkFilterBase::__in_bcount

(

len

)

const [private]

typedef BazisLib::Win32::NetworkFilterBase::__out_bcount

(

len

)

[private]

static int WSAAPI BazisLib::Win32::NetworkFilterBase::closesocket_override

(

SOCKET

s

)

[static, private]

static int WSAAPI BazisLib::Win32::NetworkFilterBase::connect_override	(	SOCKET	s,
		const struct sockaddr *	name,
		int	namelen
	)			[static, private]

void BazisLib::Win32::NetworkFilterBase::FreeAndRemoveContextForSocket

(

SOCKET

s

)

[private]

virtual void BazisLib::Win32::NetworkFilterBase::FreeUserContext

(

void *

p

)

[inline, protected, virtual]

Reimplemented in BazisLib::Network::Filters::_DummyNetworkFilter, and BazisLib::Network::Filters::BasicHTTPFilter.

SystemSocketContext* BazisLib::Win32::NetworkFilterBase::GetSystemContextForSocket

(

SOCKET

s

)

[private]

void* BazisLib::Win32::NetworkFilterBase::GetUserContextForSocket

(

SOCKET

s

)

[private]

ActionStatus BazisLib::Win32::NetworkFilterBase::InstallFilter	(	BazisLib::Network::Filters::FilterMode	mode,
		IDLLPatcher *	pPatcher
	)

typedef BazisLib::Win32::NetworkFilterBase::int

(

WSAAPI *

closesocket_ptr

)

[private]

typedef BazisLib::Win32::NetworkFilterBase::int

(

WSAAPI *

connect_ptr

)

[private]

typedef BazisLib::Win32::NetworkFilterBase::int

(

WSAAPI *

send_ptr

)

[private]

typedef BazisLib::Win32::NetworkFilterBase::int

(

WSAAPI *

recv_ptr

)

[private]

virtual void BazisLib::Win32::NetworkFilterBase::OnDisconnect	(	void *	pSystemContext,
		void *	pUserContext
	)			[protected, virtual]

Reimplemented in BazisLib::Network::Filters::_DummyNetworkFilter, and BazisLib::Network::Filters::BasicHTTPFilter.

virtual size_t BazisLib::Win32::NetworkFilterBase::OnReceive	(	void *	pSystemContext,
		void *	pSystemContext2,
		void *	pBuf,
		size_t	MaxSize,
		void *	pUserContext,
		bool	ForceBlockingMode
	)			[protected, virtual]

Reimplemented in BazisLib::Network::Filters::_DummyNetworkFilter, and BazisLib::Network::Filters::BasicHTTPFilter.

virtual size_t BazisLib::Win32::NetworkFilterBase::OnSend	(	void *	pSystemContext,
		void *	pSystemContext2,
		void *	pBuf,
		size_t	MaxSize,
		void *	pUserContext,
		bool	ForceBlockingMode
	)			[protected, virtual]

Reimplemented in BazisLib::Network::Filters::_DummyNetworkFilter, and BazisLib::Network::Filters::BasicHTTPFilter.

virtual BazisLib::ActionStatus BazisLib::Win32::NetworkFilterBase::OnStartConnect	(	BazisLib::Network::_PlatformSpecificInternetAddress *	pAddr,
		void **	ppUserContext
	)			[protected, virtual]

Reimplemented in BazisLib::Network::Filters::_DummyNetworkFilter, and BazisLib::Network::Filters::BasicHTTPFilter.

static int WSAAPI BazisLib::Win32::NetworkFilterBase::recv_override	(	SOCKET	s,
		__out_bcount(len) char *	buf,
		int	len,
		int	flags
	)			[static, private]

static int WSAAPI BazisLib::Win32::NetworkFilterBase::send_override	(	SOCKET	s,
		__in_bcount(len) const char *	buf,
		int	len,
		int	flags
	)			[static, private]

void BazisLib::Win32::NetworkFilterBase::SignalDataReceivedEvent

(

void *

pSystemContext

)

[protected]

Fires the 'receive ready' event.

This method should be called, for example, from OnSend() handler if the 'receive ready' event needs to be signaled before actual data is received from the remote side.

static SOCKET WSAAPI BazisLib::Win32::NetworkFilterBase::socket_override	(	IN int	af,
		IN int	type,
		IN int	protocol
	)			[static, private]

ActionStatus BazisLib::Win32::NetworkFilterBase::UninstallFilter

(

IDLLPatcher *

pPatcher

)

static int WSAAPI BazisLib::Win32::NetworkFilterBase::WSAConnect_override	(	IN SOCKET	s,
		IN const struct sockaddr FAR *	name,
		IN int	namelen,
		IN LPWSABUF	lpCallerData,
		OUT LPWSABUF	lpCalleeData,
		IN LPQOS	lpSQOS,
		IN LPQOS	lpGQOS
	)			[static, private]

static int WSAAPI BazisLib::Win32::NetworkFilterBase::WSAEnumNetworkEvents_override	(	IN SOCKET	s,
		IN WSAEVENT	hEventObject,
		OUT LPWSANETWORKEVENTS	lpNetworkEvents
	)			[static, private]

static int WSAAPI BazisLib::Win32::NetworkFilterBase::WSAEventSelect_override	(	IN SOCKET	s,
		IN WSAEVENT	hEventObject,
		IN long	lNetworkEvents
	)			[static, private]

---

Member Data Documentation

InProcessMutex BazisLib::Win32::NetworkFilterBase::m_ContextMapMutex [private]

WinsockPointers BazisLib::Win32::NetworkFilterBase::m_OriginalPointers [private]

NetworkFilterBase* BazisLib::Win32::NetworkFilterBase::m_pInstalledFilter [static, private]

ContextMap BazisLib::Win32::NetworkFilterBase::m_UserContextMap [private]

---

The documentation for this class was generated from the following file:

• bzswin/netfilter.h
